Wednesday, 13 March 2019

SONY KDL-32EX725/40EX725/55EX725 – HOW TO REMOVE AND ATTACH THE STAND

SONY KDL-32EX725/40EX725/55EX725 – HOW TO REMOVE and ATTACH THE STAND

SONY KDL-32EX725/KDL-40EX725/KDL-55EX725

KDL-32EX725/40EX725/55EX725 – HOW TO REMOVE and ATTACH THE STAND _ STAND ASSEMBLY PARTS & SCREW SIZES
Table-Top Stand Fixing screws for Table-Top Stand (M5 × 16) (3)
Assembling screws for Table-Top Stand (M6 × 14) (4) (for KDL-55EX72x
Assembling screws for Table-Top Stand (M6 × 14) (3) (for KDL-40/32EX72x
TABLE-TOP STAND ASSEMBLY REMOVAL
Remove 3 screws from Table-Top Stand Assembly.
Lift up TV set to detach from Table-Top Stand Assembly.
Gently place the LCD TV set face down onto a soft cloth.
STAND PARTS
[1]. >  4-267-490-01 >>  STAND, HEAD(M9) - (KDL-32EX725 ONLY)
[2]. >  4-267-497-01  STAND, HEAD(ML9) -  (KDL-40EX725/55EX725 ONLY)
[2] > 4-259-177-02  NECK (M9) - (KDL-32EX725 ONLY)
[2]. >  4-259-180-02  NECK (ML9) - (KDL-40EX725 ONLY)
[2]. >  4-259-186-02  NECK (LL9) - (KDL-55EX725 ONLY)
[3] > 4-267-555-01  STAND, BASE(M2) - (KDL-32EX725 ONLY)
[3]. > 4-267-560-01  STAND, BASE(ML2) - (KDL-40EX725 ONLY)
[3] > 4-267-566-01  STAND, BASE(LL2) - (KDL-55EX725 ONLY)
[4]. > 4-259-541-01  USER SCREW ST - (SCREWS TO ATTACH HEAD STAND AND BASE STAND TO NECK)
[5]. > 2-580-608-01  SCREW, +PSW M5X16 - (SCREWS TO ATTACH TABLE-TOP STAND TO LCD TV) (For product protection and safety reasons, Sony strongly recommends that you use the screws provided with the TV).
CAUTION: These screws cannot be used to secure the TV to the Wall Mount Brackets.
2-580-608-01  SCREW, +PSW M5X16 - (SCREWS TO ATTACH TABLE-TOP STAND TO LCD TV)
